Description CPU • Supports AMDr Ryzen 1st and 2nd Generation/ RyzenÖ with RadeonÖ Vega Graphics/ AthlonÖ with RadeonÖ Vega Graphics and A-series / AthlonÖ X4 Processors for Socket AM4 * This function will be supported depend on the CPU. Chipset • AMDr A320 Chipset Main Memory • 2 x DDR4 memory slots, support up to 32GB • Support DDR4 1866/2133/2400/2667/2933(OC)/3200(OC) Mhz* • Dual channel memory architecture • Supports ECC UDIMM memory (non-ECC mode) • Support non-ECC UDIMM memory * A-series / AthlonÖ X4 processors support a maximum of DDR4 2400 Mhz. Please refer www.msi.com for more information on compatible memory * Please refer www.msi.com for more information on compatible memory Slots • 1 x PCIe 3.0 x16 slots – Supports x 16 speed with RYZEN Series Processors – Supports x8 speed with AMDr RyzenÖ with RadeonÖ Vega Graphics and A-series / AthlonÖ X4 Processors – Supports x4 speed with AMDr AthlonÖ with RadeonÖ Vega Graphics Processors • 2 x PCIe 3.0 x1 slots Onboard Graphics • 1 x HDMIÖ port, supports a maximum resolution of 4096×2160@24Hz[1,2] • 1 x VGA port, supports a maximum resolution of 2048×1280@60Hz, 1920×1200@60Hz[1,2] 1. Only support when using AMDr RyzenÖ with RadeonÖ Vega Graphics/ AthlonÖ with RadeonÖ Vega Graphics and A-series Processors 2. Maximum shared memory of 2048 MB Storage • AMDr A320 Chipset • 4 x SATA 6Gb/s ports • Supports RAID 0, RAID1 and RAID 10 USB • AMDr A320 Chipset – 6 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector) – 6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connector) Audio • Realtekr ALC887 Codec – 7.1-Channel High Definition Audio LAN • 1 x Realtekr 8111H Gigabit LAN controller Internal I/O Connectors – 1 x 24-pin ATX main power connector – 1 x 8-pin ATX 12V power connector – 4 x SATA 6Gb/s connectors – 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) – 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) – 1 x 4-pin CPU fan connector – 1 x 4-pin system fan connector – 1 x Front panel audio connector – 2 x Front panel connectors – 1 x TPM module connector – 1 x Chassis Intrusion connector – 2 x Serial port connector – 1 x Clear CMOS jumper Back Panel I/O Ports – 1 x PS/2 keyborard/ mouse combo port – 2 x USB 2.0 Type-A ports – 1 x HDMIÖ port – 1 x VGA port – 1 x LAN (RJ45) port – 4 x USB 3.1 Gen1 Type-A ports – 3 x audio jacks Dimension • 9.6 in. x 8.1 in. (24.4 cm x 20.6 cm) • m-ATX Form Factor Mounting • 6 mounting holes Operating System • Support for Windowsr 10 64-bit • Support for Windowsr 7 64-bit * To support Windowsr 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU. Packing
